Description

Key Specifications & Highlights

• Engine: ~ 74 HP (55 kW) JCB Diesel by Kohler KDI T4F — efficient and powerful.

• Rated Operating Capacity: ~ 2,112 lbs (≈ 958 kg)

• Operating Weight: ~ 7,250-7,300 lbs (≈ 3,290 kg)

• Hydraulic Flow: standard ~ 18.5 GPM (≈ 70 L/min) with optional high-flow (~ 30-30.5 GPM / ~ 115 L/min) for demanding attachments.

• Bucket Capacity & Breakout Force: Strong lift & breakout capabilities; approximately 4,900 lb breakout force (≈ 2,200 kg) giving solid pushing/pulling performance.

• Dimensions: width ~ 60 in (≈ 152 cm), height ~ 78 in (≈ 198 cm), length ~ 137 in (≈ 349 cm)

Features & Benefits

• Vertical lift design allows you to stack loads higher and reach over obstacles more easily.

• Outstanding visibility: wide side-door for safer entry/exit; Powerboom loader design improves sightlines around machine.

• Easy maintenance: large rear service door, tilting cab option, filters and daily maintenance points accessible at ground level.

• Versatility of attachments: optional high-flow hydraulics means it can run more demanding tools (brooms, augers, grapples, etc.).

• Comfort & safety: modern cab with good space, ergonomic controls, built for operator long-hours.
