Description

This model offers Pan, Single Shaft, and Planetary mixer options to meet various concrete mixing requirements. The mixer’s wet concrete volume is 0.5 m³, providing an efficient mixing process. Additionally, the cement silos are available in internal or external options, offering flexibility with capacities ranging from 26 to 200 tons, depending on your project needs. The control system is fully automatic, simplifying processes while enhancing efficiency.

Mobil-30 provides all the features necessary to execute your projects in a smarter and more economical way. It is the ideal choice for anyone seeking productivity and convenience. Elevate your operations to the next level with this innovative mobile concrete batching plant!

Technical Specifications of the Mobil 30 Mobile Concrete Batching Plant

GENERAL FEATURES
Production Capacity: 30 m³/h
Transport Dimensions: 14.5 (L) x 2.7 (W) x 4.3 (H) meters
Weight: 16.5 tons
Total Motor Power: 70 kW
Required Electrical Generator: 80 kVA
Mixer Options: Pan – Single Shaft – Planetary
Required Area for Operation: 200 m²
Lroci Aeuf D Thjxhh Tst

TECHNICAL SPECIFICATIONS
Aggregate Stock Bunker: 4 x 10 m³
Aggregate Weighing Bunker: 0.75 m³
Aggregate Transfer Belt: 600 x 10,000 mm
Mixer Wet Concrete Volume: 0.5 m³
Cement Weighing Bunker: 300 kg
Water Weighing Bunker: 200 liters
Additive Weighing Bunker: 20 liters
Air Compressor: 300 liters, 4 kW
Csp89Ohcko
Cement Silo Option 1: Internal Type, embedded in the structure, 26-ton capacity
Cement Silo Option 2: External Type, with capacity options ranging from 50 to 200 tons
Control Type: FULLY AUTOMATIC
